Epson TM-T20II

34
Hanging the Printer on a Wall
To hang the printer on the wall, follow the steps below.
1
Attach the included control panel label for vertical installation on the roll
paper cover.
2
Install 2 screws (screw diameter: 4 mm, head diameter: 7 to 9 mm) in the
wall at an interval of 80 mm.
Make sure the length of the screw's body in the wall is 10 mm or more, and the length out-
side the wall is 3 to 4 mm.
R
 To fix the printer securely, hang the printer on a wall made of wood, concrete, or metal.
The thickness of the wall should be 10 mm or more.
 Be sure to use metallic screws.
 The screws on the wall side must have a pull-out strength of 150 N (15.3 kgf) or more.
Control panel label
for vertical installation
80 mm
{3.15"}
4 mm
{0.16"}
3 - 4 mm
{0.12 - 0.16"}
7 - 9 mm
{0.28 - 0.35"}
10 mm {0.39"}
or more
