Epson TM-T20II

40
For USB Interface
USB interface connection diagram
This printer is connected to the host computer via the USB port. When a customer display
(DM-D) is to be connected, connect it to the host computer via the serial port or USB port.
USB cable
Serial cable
Cash drawer
TM-T20II
DK cable
AC Adapter
+ AC cable
DM-D
(Serial I/F model)
DM-D
(USB I/F model)
USB cable
USB cable
DK cable
Cash drawer
AC Adapter
+ AC cable
TM-T20II
Extension cable
for power supply
