Chapter 2 Setup
43
2
Connecting the LAN cable
Connect the LAN cable to the 10/100BASE-T LAN connector by pressing firmly until the
connector clicks into place.
CAUTION
When LAN cables are installed outdoors, make sure devices without proper surge
protection are cushioned by being connected through devices that do have surge
protection.
Otherwise, the devices can be damaged by lightning.
Never attempt to connect the customer display cable, DK cable, or a telephone
line cable to the 10/100BASE-T LAN connector.
To use the Ethernet interface, EpsonNet Config is required. For detailed information about
the setup methods, see the EpsonNet Config Operations Guide.
NOT FOR TELECOMMUNICATION USE
KEIN TELEFONANSCHLUSS M6
10/100BASE-T LAN
interface connector
Button
A push button is provided to perform
the following functions.
Status sheet printing
Setting initialization
LED (Green)
LED (Yellow)
