Epson TM T88V User Manual

22
Execution result
Process execution result
Any of the following will be displayed:
 Result: Any of the following statuses will be displayed:
 Status: Any of the following printer statuses will be displayed:
String displayed
Description
SUCCESS Succeeded
ERR_PARAM An invalid parameter was passed.
ERR_ILLEGAL Used in an illegal manner.
ERR_PROCESSING Failed to execute the process.
ERR_TIMEOUT The process was timed out.
ERR_CONNECT Failed to connect to the device.
ERR_MEMORY Could not secure the memory required for the process.
ERR_OFF_LINE Offline.
ERR_FAILURE Another error occurred.
String displayed
Description
NO_RESPONSE No response from the printer
PRINT_SUCCESS Printing is successfully completed
DRAWER_KICK Status of the 3rd pin of the drawer kick-out connector = "H"
OFF_LINE Offline
COVER_OPEN The cover is open
PAPER_FEED Paper is being fed by a paper feed switch operation
WAIT_ON_LINE Waiting to be brought back online
PANEL_SWITCH The paper feed switch is being pressed (ON)
MECHANICAL_ERR A mechanical error occurred
AUTOCUTTER_ERR An autocutter error occurred
UNRECOVER_ERR An unrecoverable error occurred
AUTORECOVER_ERR An automatically recoverable error occurred
RECEIPT_NEAR_END No paper in roll paper near end sensor
RECEIPT_END No paper in roll paper end sensor

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
