Read before installation
WARNING
• Install new pipes immediately after removing old ones to keep moisture out of the refrigerant circuit.
• Chloride in Some types of refrigerants such as R22 will cause the refrigerating machine oil to deteriorate.
Necessary Tools and Materials
Prepare the following tools and materials necessary for installing and servicing the unit.
Necessary tools for use with R32 (Adaptability of tools that are for use with R22 and R407C)..
1 - To be used exclusively with R32 ( Not to be used if used with R22 or R407C)
Tools/Materials Use Notes
Gauge Manifold Evacuating, refrigerant charging 5.09MPa on the High pressure side.
Charging Hose Evacuating, refrigerant charging Hose diameter larger than the conventional ones.
Refrigerant Recovery
Equipment
Refrigerant recovery
Refrigerant Cylinder Refrigerant charging Write down the refrigerant type. Pink in color at the top of the cylinder .
Refrigerant Cylinder Charging
Port
Refrigerant charging Hose diameter larger than the conventional ones.
Flare Nut Connecting the unit to piping use Type-2 Flare nuts.
2 - Tools and materials that may be used with R32 with some restrictions.
Tools/Materials Use Notes
Gas leak detector Detection of gas leaks The ones for HFC type refrigerant may be used.
Vacuum Pump Vacuum drying May be used if a reverse flow check adaptor is attached.
Flare Tool Flare machining of piping. Changes have been made in the flare machining dimension. Refer to the
next page.
Refrigerant Recovery
Equipment
Recovery of refrigerant May be used if designed for use with R32
3 - Tools and materials that are used with R22 or R407C that can also be used With R32
Tools/Materials Use Notes
Vacuum Pump with a Check
Valve
Vacuum drying
Bender Bending pipes
Torque Wrench Tightening flare nuts. Only ∅ 12.70 (1/2") and ∅ 15.88(5/8") have a larger flare machining dimen-
sion.
Pine Cutter Cutting pipes
Welder and Nitrogen Cylinder Welding pines
Refrigerant Charging Meter Refrigerant Charging
Vacuum Gauze Checking vacuum degree
4 - Tools and materials that must not be used with R32
Tools/Materials Use Notes
Charging Cylinder Refrigerant charging Must not be used with R32 -type units.
Tools for R32 must be handled with special care, and keep moisture and dust from entering the cycle.
