ERBAUER 254MM (10”) SINGLE BEVEL SLIDING MITRE SAW
15. CARRYING HANDLE
16. SLIDE CARRIAGE
17. BEVEL LOCK HANDLE
18. RIGHT EXTENSION TABLE
19. MOTOR
20. POSITIVE STOP LOCKING LEVER
21. LOWER BLADE GUARD LOCK LEVER
/$6(5212))6:,7&+
23. ADJUSTABLE CUTTING STOP
Fig 2
15
17
18
20
21
22
23
16
19
