Erbauer ERB238MSW - Adjusting the Angle of the Laser Guide

ERBAUER 254MM (10”) SINGLE BEVEL SLIDING MITRE SAW

are provided. Two (1,2) are positioned on the LH
side of the laser housing, and one (3) on the RH
side of the laser housing. These screws gently
hold the laser module in place and on alignment
by bearing on the laser modules casing. It is

on the laser module casing is maintained as
closely as possible to the factory setting. Do not
over tighten any one screw – damage to the laser

B Adjusting the Angle of the Laser Guide
1) Loosen the single screw on the RH side of
the laser housing ½ a turn.
2)Turn the laser element in the desired direction


C Aligning the Laser Beam

of the laser housing.

achieved.
Warning: Use only the correct sized
  
screws. Turn one screw at a time and only ¼
turn in either direction before checking laser
alignment. Maintain as far as possible the
original factory pressure setting that these


Fig 17
1
3
2
