ERBAUER 254MM (10”) SINGLE BEVEL SLIDING MITRE SAW
10. Cutting bowed material
A bowed workpiece must be positioned against
the fence and secured with a clamping devise
before cutting as shown.
Warning: Do not position workpiece
incorrectly or try to cut the workpiece
This will cause the blade to bind and could
11. Satellite workpiece support
Incorporated into the LH side of the machine
base is a removable satellite stand. Use this
stand to help support long pieces of material.
To remove the satellite stand, press the release
button on the top, and slide the stand from the
machine base. Position where convenient to
To replace, simply slide the satellite stand back
into the machine base until the release button
12. Adjustable stop plate
Fig 34
Fig 35
