ERBAUER 254MM (10”) SINGLE BEVEL SLIDING MITRE SAW
6. Bevel adjustment 33.9
o
° settings can be checked
°
the crown moulding pin. Check the angle of
the blade against the machine table using the
(3) to the relevant socket headed stop screw.
angle is achieved. Retighten the locknut. (See
7. Mitre angle adjustment
The sliding compound mitre saw scale can be
mitre saw table has nine of the most common
and accurately. Follow the process below for
1) Unlock the mitre table by turning the mitre
handle (1) counterclockwise.
2) Move the turntable while lifting up on
the positive stop locking lever (2) to align
the indicator (3) to the desired degree
measurement.
3) If the desired angle is one of the nine positive
stops, release the positive stop locking lever,
making sure the lever snaps into position, and
then secure by tightening the mitre handle.
4) If the mitre angle desired is not one of the
nine positive stops, simply lock the mitre table
into position by turning the mitre handle in the
8. Mitre scale indicator adjustment
2) Loosen the screw (4) that holds the indicator
with a Phillips screwdriver.
Fig 24
Fig 23
1
2
4
3
