Erbauer ERB238MSW - Mitre Cut; Bevel Cut

ERBAUER 254MM (10”) SINGLE BEVEL SLIDING MITRE SAW
Warning:
materials being thrown, always
unplug the saw to avoid accidental starting,
and remove small pieces of material from the
table cavity.
6. Mitre cut

mitre table by turning the mitre handle (1)
counterclockwise.
2) While holding the mitre handle, lift up on the
positive stop locking lever (2).
3) Rotate the mitre table to the right or left
with the mitre handle.
4) When the table is in the desired position,
as shown on the mitre scale (3), release the
positive stop locking lever and tighten the
mitre handle. The table is now locked at the
desired angle. Positive stops are provided at

IMPORTANT
Always tighten the mitre table lock handle
before performing every cutting operation.
7. Bevel cut

bevel lock handle (1) by turning it clockwise.
2) Tilt the cutting head to the desired angle, as
shown on the bevel scale (2)
3) The blade can be positioned at any angle,
°° on the scale) to a

(1) to lock the cutting head in position.
°° and
45°
Note: When cutting at 45 degrees, ensure
guard does not catch on work or machine
base plate.

Fig 31
3
1
2
1
2
