1TEST PROGRAMS AND ADJUSTMENTS51 / 266
Art. No.: 80116-201
09 / 2004
Using the “Up” (8) and “Down” (9) keys, call up an adjustment test number. Start the adjustment test with
key 3.
Test program no. 16
List of individual adjustments
Test program 16: List of individual adjustments
Adjustment
Function of the adjustment
1 Phase relationship of the power supply unit
2 Current/voltage setting of the power supply unit
3 Setting of the actuation pulse length for the HF generator
4 Phase relationship of the HF generator
5 Current/voltage setting of the HF generator
6 Current/voltage setting of the amplified measurement values of the HF generator
7 Phase angle setting (cos Phi)
8 Adjustment of the function monitor sensor
9 NESSY adjustment: Contact resistance
10 HF leakage current monitor
11 Starting threshold of the contact monitor
12 Length of actuation pulse and frequency setting of the ST generator
13 LF leakage current measurement and setting help for CF
