1 TEST PROGRAMS AND ADJUSTMENTS28 / 266
Test program no. 9
Activating display programs to display
measurement values
General description
This program activates displays in the standby mode or during activation. With key 3, Test program no. 9 is
started.
After starting, you will see the following display:
Display
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
nr. 0
Within Test program no. 9, 22 subprograms for displaying specific data can be called up, while subprograms
16 to 22 are intended only for use by the manufacturer.
These subprograms can now be set using keys 8 (Up) or 9 (Down). Once the required display program has
been selected, it is reactivated using key 3. The selected display program remains activated until the power
is switched off.
Display
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
nr. 0 ... 22
