1 TEST PROGRAMS AND ADJUSTMENTS50 / 266
General description
All adjustment work is performed solely with the help of this test program. Here the sequence from
Adjustment 1 to Adjustment 13 must be followed.
Ending the test is only possible at the setting Adjustment 0 (as of 0 in the display).
If Test program 16 is activated, the test program is automatically called up again if there is a brief power
failure lasting up to approx. 15 seconds. If the power failure lasts longer than 15 seconds, the test program
is no longer automatically called up.
This text describes only the function of the program. The unit is adjusted according to the adjustment
instructions. These adjustment instructions are a component of the service documents.
After starting the test program with key 3, you will see the following display:
Display ICC 350 / 300
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
Ab
xx (0 … 13)
xx Adjustment test number (beginning with 0)
Display ICC 200
AUTO CUT AUTO COAG
Ab
xx
xx Adjustment test number (beginning with 0)
Adjustment 0 permits entry and exit from Test program 16.
Test program no. 16
General description
