1TEST PROGRAMS AND ADJUSTMENTS45 / 266
Art. No.: 80116-201
09 / 2004
Measuring equipment
To service equipment from the ICC series, various meters are necessary. The following list summarizes
recommended measuring equipment for a quick overview.
ATTENTION !
Individual parts and boards are at supply voltage potential. After removing the housing cover, there is risk of
electrical shock due to unintentional contact with the power plug connected.
The HF power meter, the oscilloscope and the frequency counter must be operated as floating.
The unit contains a lithium battery which must only be discarded in battery collection containers in completely
discharged condition (i.e. after use). Otherwise, care must be taken to prevent shorting in accordance with
the battery regulations.
Test program no. 16
Pre-information:
Recommended measuring equipment
Measuring equipment
EE order no.
(230 V; 50/60 Hz)
EE order no.
(120 V; 50/60 Hz)
Testbox 2 20183-040 20183-041
70 V testbox for spark monitor ICC 20100-019 20100-028
HF power meter —
Isolating transformer for APM 600 20100-013
Adapter cable for NESSY monitor 20100-003
Bipolar adapter cable 20100-004
Measurement cable for LF patient leakage current 20100-009 (standard)
Measurement cable for LF patient leakage current 20100-012 (international)
2-channel oscilloscope (> 40 MHz) —
Frequency counter —
Multimeter with µA range —
Bipolar testbox automatic starter ICC 20100-017
Extension board 30183-106
