The maximum charging current flows if the temperature of the battery pack
is between 5 - 40°C. Avoid battery temperatures below 0°C when charging.
You achieve the longest life span, if the battery pack is charged daily
and is not being operated until the control unit switches off.
(only the yellow LED light is shining on the control box).
During charging, the battery pack always has to be in a horizontal position
(cover upside, battery must not be in upright position).
- 21 -
Fig. 10d
6.) To remove the blue charging plug after
charging is completed please proceed
as follows:
a) pull the silver locking bar (15)
backwards
b) turn the plug by 45° counter clockwise
c) remove the plug
Fig. 11
15
Attention!
The charging time is approximately 8 hours. The battery pack is fully charged
not before both LED indication lights on the charger are shining green!
