2. Step
2 LEDs (green and yellow) are now flashing. The control unit is in
teaching mode.
Now move the joystick (8) completely to “move out“ or “move in
direction“ and keep it pushed until the green LED permanently is
shining (if the green and the yellow LED are shining, the battery is
not fully charged but you nevertheless can continue).
The control unit/ sealing head is ready for operation.
6.2 Switching on the control unit
1. Step
Charge the battery pack as described under 5.2.
Plug in the connector of the power cable (13) into the socket of the
battery pack (7) and lock it by turning the red ring (12) clockwise.
Lock the cover of the battery case again.
Turn the main switch (11) to the right to operating mode “1“
Set the operating mode switch (10) to operating mode “A“.
13 12
7
11
10
8
- 23 -
Fig. 14 Fig. 15
