1. Technical Data
- 6 -
1.1 Strapping system
Weight:
ErgoPack 700 64,4 kg
ErgoPack 700E (incl. battery pack) 88,1 kg
ErgoPack 713E (incl. battery pack) 92,1 kg
ErgoPack 726E/745E (incl. battery pack) 92,9 kg
Dimensions (all types) Length 630 mm
Width 770 mm
Height 1200 mm
Maximum chain speeds
Mode A, strapping
Moving out horizontally: 40 m/min
Moving out vertically: 60 m/min
Moving in vertically: 44 m/min
Moving in horizontally: 54 m/min
Mode B: setting up/threading strap
Moving out 20 m/min
Moving in: 16 m/min
Max. chain thrust: 310 N
Measured A-graded
noise emission level L pa 79 dB (A)
(EN ISO 11202)
7.6 Changing the sealing head 62-63
7.7 Changing the control box with the motor 64-65
7.8 Cleaning/replacing the tension wheel at the sealing head 66
7.9 Cleaning/replacing the tooth plate at the sealing head 67
7.10 Replacing the cutter at the sealing head 68
8 Save moving and parking 69
9 Spare parts lists 69
10 General safety warnings for power tools 70-73
