- 26 -
Press the "Operating mode" button (1).
• Unused displays disappear.
• The currently set operating mode flashes
for 5 seconds.
• + and – appear.
Press the + (2) or – (3) button until the
desired operating mode is displayed.
MAN / SEMI / AUTO
By pressing the "Operating mode" button (1) again, or after waiting for a
period of 5 seconds, the set mode is saved.
Every operating mode can also be selected for the "Soft tension" tension
range (Side 24).
Fig. 17b
3
2
1
• MAN-Manual
The tensioning button must be pulled and held until the desired strap
tension has been reached. The welding button must then be briefly
pressed so that the straps are welded and the upper strap is cut off.
• SEMI–Semi-automatic strapping (standard/factory setting)
The tensioning button must be pulled and held until the set tension force
has been reached. The straps are then automatically welded and the
upper strap is cut off. It can be welded manually at any time by pressing
the welding button.
• AUTO–Fully automatic strapping*
The tensioning button has to be pulled (touched) once only. This triggers the
tensioning process. Once the set tension force has been reached, the straps
are automatically welded and the upper strap is cut off.
* This operating mode AUTO = Fully automatic strapping is factory
blocked! Activation only through your ErgoPack service partner possible.
6.5 Setting mode of operation at the sealing head
WARNING
Strap tensioning or strapping, danger of jamming and crushing
Do not place hands or other body parts between the strap and the packaged goods
during the strapping process. Ensure that there are no other persons in the hazard zone
For an emergency stop in the case of danger (trapped person):
To release the strap tension (before welding), actuate the rocker lever. In operating mode
AUTO, also the tensioning or welding button can be pressed again. After welding, cut the
strap using a tool (strap cutter).
