Table of contents
Page
1 Technical data 6
1.1 Strapping system 6
1.2 Sealing head 7-8
1.3 Battery and charger 9
2 General 10-11
2.1 Notes on environmental protection 11
3 Safety regulations 12-15
3.1 Safety regulations for battery pack and charger 15
4 Description 16
4.1 Construction 16
4.2 Operating panel strapping system 17
4.3 Operating panel sealing head 17
4.4 Indications of the Dual-Charger 18
5 Commissioning 19
5.1 Battery charger 19
5.2 Charging the battery pack 19-21
6 Operation 22
6.1 Setting strap width at the sealing head 22
6.2 Switching on the control unit 23
6.3 Setting strap tension range at the sealing head 24
6.4 Setting strap tension at the sealing head 25
6.5 Setting mode of operation at the sealing head 26
6.6 Select favorite 27
6.7 Changing strap coil 28-41
6.8 Strapping 42-46
6.9 Tensioning and sealing pallets above 70 cm height 47-50
6.10 Sealing control 51
6.11 Setting welding time 52
6.12 Tensioning and sealing of pallets
below 70 cm height 52-54
7 Service and repair 55
7.1 Cleaning the ChainLance 55
7.2 Replacing the ChainLance 56
7.3 Replacing individual chain links 57
7.4 Replacing the reversing sledge 58-59
7.5 Replacing the length adjusting belt 60-61
