BEA--220265-EN-04 BPage11
CCDarraycameraOptoLineOL80..
➜Runelectricalleadsaccordingtotheattachedwiringdiagramand
EMCinstructions.
➜ProtectandrunCANbuslinesawayfromnoisyorheavycurrent-
carryingleads.
 Ensure that:
insulation is not damaged and the leads properly secured
and protected.
the total length of the CAN bus line is limited to 200 m and
may not exceed this.
a terminating resistor connector is attached to both ends of
the CAN bus line. 3-pole plugs are used as CAN bus connec-
tors.
when using your own light transmitters, that they feature an
electronic ballast (min. 5 kHz).
Procedur
7.1 Positioncamera
7.2 Checkwiring
7.3 Checksupplyvoltage
7.4 Set/checkcameraCANaddress
7.5 Positionwebedgeinthecameravisualrange
7.6 Setcameraapertureandfocusing
  A.aperture
  B.focusing
7.7 Congurecamera
7.8 Calibratecamera
7.9 Calibratewidthmeasurement
7.10 Performapplication-dependentsettings
7. Commissioning
6. Installation
