Erhardt+Leimer OL 80 - Page 29

BEA--220265-EN-04 BPage29
CCDarraycameraOptoLineOL80..
No. Name Default Min Max Access Description
.1.4. position 0 -32768 32767 R/W Outputmeasuredvalue
(contrastingedgesetposition)
.17. lenstype 2 0 3 R/W Denelens
Lens  Linearisation
0=undened off
1=24mm on
2=28mm on
3=50mm off
.18. templatewidth 0.0 0.0 3250.0 R/W Widthofcalibratingtemplateinmm
.19. templateoffset 0 -3000.0 3000.0 R/W Distancefromref.pointtotem.inneredge
(e.g.machinecenter-templateinneredge)
.21. calibrationpixels 0 0 32677 R/W Totalmeasuringrangeinsubpixels
.22. calibrationwidth 0 0 32677 R/W Totalmeasuringrangeinmm

.28.
exp.adjusttype 0 0 2 R/W Typeofexposurecontrol
0=exposurecontrolalwaysactive
1=exposurecontrolonlyactiveifnoweb
2=isinthescanningrange
.3.2. edgedetectfunction 0 0 1 R/W Typeofedgeevaluation
0=edgeevaluationbyankheight
1=edgeevaluationwithgreyscalethreshold
Thelimitvaluesaresetinparameters33and34.
.3.3. topthresholdvalue +30 -255 255 R/W Upperthresholdvalueforedgeevaluation
DieThefunctionofparameter33dependsontheedge
evaluationsetinparameter32.
Parameter32=0:minimumheightofavalid,
positiveank(pos.value)
Parameter32=1:greyscalethresholdthatmustbe
exceededbyavalidedge(pos.value)
.3.4. downthresholdvalue -30 -255 255 R/W Lowerthresholdvalueforedgeevaluation
Thefunctionofparameter34dependsontheedge
Parameter32=0:minimumheightofavalid,
negativeank(neg.value)
Parameter32=1:greyscalethresholdbelowwhich
avalidedge(pos.value)mustnotdrop
.4.1. sendmountposition 0 0 1 R/W SendmountingpositiontoCANbus
1=yes
0=no
.4.2. enablephoto 1 0 1 R/W Activatephotomode
(Storemeasuredvaluesetposition)
0=photomodenotpossible
1=photomodepermissible
.4.7. subsystem0adress 00 00 0F R/W addressfor2ndmeasuredvalue
Addressconsistsofgroupanddevicenumbers
Values:0.1,0.2,0.3,0.4...7.1,7.2,7.3,7.4variable
: :
.5.3. subsystem6adress 00 00 0F R/W CANaddressfor8thmeasuredvalue
