35
When conditions 1 or 2 are not satisfied, the instrument will reject
the new value showing the "0" and it will maintain the cursor on the
rejected parameter.
3) The value assigned to "H.RANGE EU" parameter can be lower
than the value assigned to "L.RANGE EU" (reverse read-out).
Push the FUNC push-button; the cursor will go automatically on the
lower line.
By the numerical keyboard, set the desired read-out assigned to
the initial scale value (For Example 1, it is equal to -100.0 mBar).
Depress the FUNC push-button.
NOTES: For the read-out in eng. units, the number of decimal
figures is free with respect of the read-out limits (20000 counts).
The display will show the following:
By the numerical keyboard, set the desired final scale value (For
Example 1, this value is equal to 10000 mV).
Push the FUNC push-button.
By the numerical keyboard, set the desired read-out assigned to
the final scale value (For Example 1 this value is equal to 1000.0
mBar).
Push the FUNC push-button.
NOTE For the read-out in eng. units, the number of decimal figures will
be equal to the decimal figure programmed in "L.RNG EU".
The instrument will start to measure and, for Example 1, if a 3 V
signal is applied to the input terminal the display will show:
NOTES:
1) The instrument will automatically select the input range contain-
ing the two programmed values ("L.RANGE mV" and "H.RANGE
mV") with the maximum resolution.
2) During mV measurement with programmable read-out scaling it is
possible to enable/disable, by the REV/MOD push-button, the
scaling function and to display the measured value in mV.
3) During mV measurement, the instrument is able to measure and
display up to 5 % more than the upper programmed value or 5%
less than the lower programmed value.
3.6.3 - RNG ( ) - mV measurement with square root extraction
on the measured value and read-out scaling.
Selecting the RNG ( ) option, the instrument extracts the square
root of the measured value and scales it according to the pro-
grammed range.
Example 2 : with a quadratic input range from 1 to 5 V it is desired
to have a read-out going from 0.0 to 1500.0 (m
3
/h).
H.RNG XXXXXX mV
H.RNG XXXXXX EU
MEAS RNG(L)mV
229.9 EU
