4 INSTALLATION
0447 209 001
- 12 -
© ESAB AB 2022
4.2 Lifting instructions
Mechanical lifting must be done with both outer handles.
4.3 Mains supply
NOTE!
Mains supply requirements
This equipment complies with IEC 61000-3-12 provided that the short-circuit power is greater
than or equal to S
scmin
at the interface point between the user's supply and the public system.
It is the responsibility of the installer or user of the equipment to ensure, by consultation with
the distribution network operator if necessary, that the equipment is connected only to a supply
with a short-circuit power greater than or equal to S
scmin
. Refer to the technical data in the
TECHNICAL DATA chapter.
Make sure it is protected by the correct fuse rating. A protective earth connection must be made, in
accordance with regulations.
1. Rating plate with supply connection data
