ESAB Rogue ET 200iP User Manual

3 TECHNICAL DATA
0463 769 001
- 8 -
© ESAB AB 2021
3 TECHNICAL DATA
Technical data
Rogue ET 200iP
Outlet voltage 230V±15%
1~ 50/60Hz
Primary current
I
max
MMA
43A
I
max
TIG
16.5A
No-loadpowerdemand when in
energy-saving mode 50W
Setting range
MMA 20-200A
TIG 10-200A
Permissible load at MMA
25% duty cycle 200A/ 28V
60% duty cycle 129A/ 25.2V
100% duty cycle 100A/ 24V
Permissible load at TIG
25% duty cycle 200A/ 18V
60% duty cycle 129A/ 15.2V
100% duty cycle 100A/ 14V
Apparent power I
2
at maximum current
6kVA
Active power I
2
at maximum current
5.94kW
Power factor at maximum current
TIG 0.63
MMA 0.63
Efficiency at maximum current
MMA 89%
TIG 89%
Open-circuit voltage U
0
max
VRD 35 V deactivated 63VDC
VRD 35 V activated <30V
Operating temperature -10to+40°C
(+14to 104°F)
Transportation temperature -20 to +55°C
(-4 to +131°F)
Continual sound pressure at no-load <70dB
Dimensions l×w×h 403×153×264mm
(15.9×6×10.4in.)
Weight 8.7kg
