APPENDIX 2 - APPLICATION SOFTWARE GUIDE
When some parts are replaced it will be necessary to reprogram, reconfigure or recalibrate the table PCAs. The
following list provides guidance on which parts and what actions need to be taken, when these parts are changed.
After reassembling the table but before refitting covers (especially the short trunk black top in some cases) the table
should be connected to a PC (boards and protractor if required) to enable the following procedures to be followed.
Consult the ‘Application Software Manual’.
Three actuator (3 axis) PCA
Program 3-axis controller
Configure 3-axis controller
Calibrate break right
Calibrate break left
Four actuator PCA
Program main controller
Configure main controller
Program actuator controller
Configure actuator controller
Calibrate tilt
Calibrate Trend
Calibrate height
Telescopic column assembly
Recalibrate height
Tilt bush
Recalibrate tilt
Recalibrate Trend
Tilt actuator
Recalibrate tilt
Trendelenburg actuator
Recalibrate Trend
Trendelenburg bush
Recalibrate tilt
Recalibrate Trend
Bearing pads
Recalibrate height
Break gearbox
Recalibrate break right or,
Recalibrate break Left as applicable
Break potentiometer loom
Recalibrate break right or,
Recalibrate break Left as applicable
Tilt/Trend loom (includes potentiometers)
Recalibrate tilt
Recalibrate Trend
Height potentiometer loom
Recalibrate height
Break gearbox loom
Recalibrate break right or,
Recalibrate break Left as applicable
