SENSOR
UNCALIBRATED
• Calibrate the controller. Refer to test report to calibrate.
Sash
Position
Function Available
Normal Or Quickstart
Mode and Airfail Alarm
On
Normal Or Quickstart
Mode and Airfail Alarm
Off
Maintenance Mode
READY
Sash Position Detection
Yes
Yes
Yes
Fan Control
Yes, with WARM UP &
PURGING time, FAN PIN
required
Yes, with WARM UP &
PURGING time, FAN PIN
required
Yes, without WARM UP &
PURGING time, no PIN
required
Light Control
Yes
Yes
Yes
Socket Control
Yes
Yes
Yes
UV Control
Interlocked
Interlocked
Interlocked
MENU Access
Yes,
USER or ADMIN PIN
required
Yes, USER or ADMIN PIN
required
Yes, no PIN required
Pressing Set button
Complete Diagnostic
Message
Complete Diagnostic
Message
Complete Diagnostic
Message
Timer
Yes
Yes
No
Current Time Display
Yes
Yes
Yes
Air Velocity
Display
Yes
Yes
Yes
If not calibrated, displaying “Sensor Uncalibrated”
Air Velocity Display Status
Yes
Yes
No
Air Fail checking
Yes, Alarm and display alert
if air fails
No No
SASH
ALARM
Sash Position Detection
Yes
Yes
Yes
Current Time Display
Ye
s
Yes
Yes
Sash Alarm
Yes, not mutable
Yes, not mutable
Not Applicable
Fan Control
Yes, without WARM UP &
PURGING time, no PIN
required
Yes, without WARM UP &
PURGING time, no PIN
required
Yes, without WARM UP &
PURGING time, no PIN
required
Light Con
trol
No
No
Yes
Socket Control Yes Yes Yes
UV Control
Interlocked
Interlocked
Interlocked
Air Velocity Display
Yes
Yes
Yes
Air Velocity Display Status
Yes
Yes
No
Air Fail checking
Yes, display alert if air fails
No
No
FULLY
OPEN
Sash Position Det
ection
Yes
Yes
Yes
Current Time Display
Yes
Yes
Yes
Alarm Yes, mutable for 5 minutes Yes, mutable for 5 minutes Not Applicable
Fan Control
Yes, with WARM UP &
PURGING time, FAN PIN
required
Yes, with WARM UP &
PURGING time, FAN PIN
required
Not Applicable
Light Control Yes Yes Yes
Socket Control Yes Yes Yes
UV CONTROL
Interlocked
Interlocked
Interlocked
FULLY
CLOSED
Sash Position Detection
Yes
Yes
Yes
SWITCH OFF Fan requested
Yes
Yes
No
Fan Control
Interlocked
Interlocked
Yes
Light Contro
l
Interlocked
Interlocked
Yes
Socket Control Yes Yes Yes
UV Control Yes Yes Interlocked
