 Diode Test/Continuity
Resolution, Full Scale Reading and Accuracy
Range Resolution Full Scale Reading Accuracy
2.3V
100µV
2.3000V 0.05% + 5
• Open Circuit Voltage / Test Current: +6.0V dc / 0.5mA approx.
• Audible Tone: Continuous beep for continuity and single tone for normal forward-biased
diode or semiconductor junction
• Continuity level: Approximately below +50mVdc
• Maximum Input Protection: 500V dc or ac rms

Frequency
Resolution, Full Scale Reading and Accuracy
Range
Measuring
Range
Resolution
Full Scale
Reading
Accuracy (1 year)
500 Hz 5Hz~ 500Hz 0.01 Hz 510.00 0.01 + 5
5kHz 500Hz~5kHz 0.1 Hz 5.1000 0.01 + 3
50kHz 5 KHz~50 kHz 1 Hz 51.000 0.01 + 3
500kHz 50kHz~500 kHz 10 Hz 999.99 0.01 + 3
• Response Time: Approximate 1 second when the displayed reading reaches 99.9% of
frequency value.
Sensitivity for Voltage Measurement
Minimum Sensitivity (RMS Sine-wave)
Input Range
5Hz ~ 100kHz 100kHz ~ 500kHz
500 mV 35mV 200mV
5V 0.25V 0.5V
50V 2.5V 5V
500V 25V NO SPEC.
750V 50V NO SPEC.
• Maximum input V-Hz and Input Impedance, please refer to AC Voltage measurement.
Sensitivity for Current Measurement
Minimum Sensitivity (RMS Sine-wave)
Input Range
30Hz~20kHz
500µA 35µA
5mA 0.25mA
50mA 2.5mA
500mA 25mA
5A 0.25A (<2kHz)
10A 2.5A (<2kHz)
• Maximum input, please refer to AC Current measurement.
