Table of Contents
Section 1. Introduction
1-1 Introducing the 50,000 Count Dual Display Multimeter 1
1-2 Features 2
1-3 Options and Accessories 3
1-4 How to use this manual 4
1-5 Safety 5
Section 2. Getting Started
2-1 Introduction 7
2-2 Getting Started 7
2-3 Turning the Meter ON 11
2-4 Selecting Current Input Terminals and 11
Measurement Range
2-5 Using the Pushbuttons 11
2-6 Basic Measurement Examples 12
2-7 Rack Mounting 18
Section 3. Front Panel Operation
3-1 Introduction 19
3-2 Front Panel Operations 19
3-3 Primary and Secondary Displays 20
3-4 Input Terminals 22
3-5 Initialization of Measurement Conditions 23
3-6 Selecting A Measurement Function 23
3-7 Selecting Measurement Range 26
3-8 Selecting Secondary Display 27
3-9 Entering Setup Mode 29
3-10 Selecting Local Operation Mode 31
3-11 Operating Arithmetic Functions 31
3-12 Selecting Trigger Mode 38
Section 4. Measurement Applications Examples
4-1 Introduction 41
4-2 Applications for Using Dual Display 41
4-2-1 Dual Display Operation Examples 42
4-3 Measuring Resistance 45
4-4 Measuring True RMS AC+DC 46
