6-5-2 Set Commands
 S1 command
The S1 command is used to set up the measurement functions, ranges, and reading
rates for the primary display in the meter.
The S1 command is followed by two parameters <f> and <r> in order.
All characters for the <f> and <r> parameters must be in the upper case.
For detail information of using the S1 command, see Table 6-4 and Table 6-6.
Table 6-4. Descriptions for S1 Command
Syntax Description
In S1 command,
<f>
and
<r>
parameters are used to set up the primary
display measurements:
<f>
for specifying measuring functions,
<r>
for specifying ranges.
<f>
is a necessary parameter for specifying the measuring functions.
<f>
parameter is defined by a numeric value from “0” to “9” and
character “A” and “B”.
<r>
is an optional parameter for specifying measurement range.
<r>
parameter is defined by a numeric value from “0” to “6”. If
<r>
parameter is omitted, the value is assumed to “0”.
S1
<f><r>
Table 6-6 shows all available S1 command parameters and available
combinations.
Example 1: “S142”
Set primary display to DCA 5mA with manual range.
Example 2: “S17” (
<r>
is omitted)
Set primary display to frequency with auto ranging.
