Section 4
Measurement Application Examples
4-1 Introduction
Section 4 describes some advanced features and applications that help the
user to operate the meter more effectively. The user must be familiar with the
basic measurement operations described in Section 2 and Section 3 and has a
basic understanding of electronics knowledge.
4-2 Applications for Using Dual Display
The dual display capability is one of the most useful features provided with
the meter. User may take the advantages to greatly enhance the test and
measurement capabilities.
Some common combinations and applications of using dual display are
provided in Table 4-1.
Table 4-1. Typical Combinations and Applications for Using Dual Display
Primary
Display
Secondary
Display
Applications
Vdc Vac
Vac+Vdc Vdc
• Testing DC to AC or AC to DC converter circuit
• Measuring DC level and AC ripple of power supply
Vac Hz
• Measuring AC frequency response of amplifier circuit
Aac Hz
• Adjusting AC motor control
Adc Aac
Aac+Adc Adc
• Measuring AC ripple and DC current of power supply
• Measuring current dissipation for power supply analysis
dBm
Reference
Ω
• Setting dB reference impedance and show dBm
dBm Vdc
• Indicating DC voltage and dBm
dBm Vac
• Indicating AC voltage and dBm
