A-3 General Specifications
General Items Specifications
Warm up time At least 30 minutes
Temperature Coefficient
Add 0.15 x (the applicable accuracy)/°C at 0°C to 18°C and
28°C to 50°C
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-20°C to 60°C
Altitude Up to 2000 M
Pollution Degree II
Over-voltage Category CAT III-600V and CATII-1000V
Relative Humidity
Up to 80% (60% for 50MΩ range of resistance measurement)
Common Mode Voltage
1000V dc or peak ac rms maximum between any input and
earth ground
Dimension Approx. 255(w) x 105(h) x 305(d) mm (with holsters)
Weight <3.0kgs
Line Voltage
100V / 120V / 220V / 240V ac ±10%, 50/60Hz, 16VA maximum
Interface
RS-232 (DB-9, male connector)
Baud rates: 9600, 4800, 2400, 1200, 600, 300
Data length: 7 or 8 bits
Parity: even / odd / none
Stop bit: 1 or 2 bits
Echo: on / off
Print mode: on / off
Safety Requirement Designed in compliance with EN61010-1 (IEC1010-1)
Installation Category
CAT-II 750VAC/1000VDC or CAT-III 600V, Pollution Degree
II Environment
EMC Requirement Designed in compliance with EN61326-1.
