Appendix A
Specifications
A-1 Introduction
Appendix A describes the complete specifications of this meter.
A-2 Technical Specifications
Specifications assumptions:
• One-year calibration cycle.
• Operating temperature at 18°C to 28°C (64.4°F to 82.4°F).
• Accuracy is expressed as: ± (% of reading + digits) after 30 minutes warm-up.
• Temperature coefficient: Add ± [0.15 x (the applicable accuracy)/°C] for 0°C
to 18°C and 28°C to 50°C.
• Relative Humidity (RH): up to 80% (60% for 50MΩ range of resistance
measurement).
• All specifications are specified under single display mode in operation only.
Display Counts and Reading Rates
Full Scale Display Counts: 51,000 Counts
Reading Rate (Approx.)
Measuring Function Readings/Sec Measuring Function Readings/Sec
DCV 3 DCV / Frequency 1.3/2
DCA 3 ACV / Frequency 3/2
Diode 3 ACV+DCV / Frequency 1.3/2
ACV 3 DCA / ACA 1.3
ACA 3 ACA+DCA / DCA 1.3
Ω
3 ACA+DCA / ACA 1.3
Frequency/ACV or ACA 2/3 DCA / Frequency 1.3/2
ACV+DCV 1.3 ACA / Frequency 3/2
ACA+DCA 1.3 ACA+DCA / Frequency 1.3/2
DCV / ACV 1.3 dBm / DCV 3
ACV+DCV / DCV 1.3 dBm / ACV 3
ACV+DCV / ACV 1.3 dBm / ACV+DCV 1.3
Notes:
1. The reading rate is measured as above combinations and applications at lock range.
2. Using RS-232 or GPIB remote interface, the reading rate is similar to normal mode.
