4-3 Measuring Resistance
1. Connect a resistor under test to and
COM
input terminals as shown
below:
POWER
WARNING!
Do not apply a voltage exceeding 500 V peak between and COM input terminals.
2.
to select
Ω
measurement.
3.
, or to select auto-ranging or manual range for
primary display.
Note: When measuring low resistance, use “REL” modifier function to reduce the
measuring error created by the test leads resistance and contact resistance in
the test loop (0.1
Ω
~ 0.5
Ω
typical).
45
