Operation Procedures for Front Panel
To enable an external trigger and trigger a measurement from the front panel,
perform the following procedures:
1. Press then followed by to enter trigger mode and standby
condition. The annunicator of TRIG will be lit, and display is indicated
with “
”.
2. Press
to get a new value. After a measuring, then the result will be
indicated and held on display.
3. Press
to get a new value again.
4. Press
, or to select auto-ranging or manual range as
necessary.
5. Press other function keys to select what you want.
6. Press
then followed by to disable external trigger.
Notes
:
1. When external trigger is enabled, all the arithmetic functions will be
disabled.
2. Press
then followed by may disable external trigger also.
3. The trigger mode will disable the secondary display except frequency
function in primary display.
39
