The Test Keyboard function enables the user to select each button to
ensure the correct function on the screen. Press the ESC key TWICE
to exit the menu.
The Silent Test function allows the selection of one or more detection-
zones to operate in a ‘silent one-man walk test mode’. On triggering a
device, the device LED operates but the sounder does not sound and
the control panel indicates an alarm. After approximately 5 seconds the
system will reset the device and another may be tested. The control
panel event log will indicate that a test mode has been selected. This
operation will also enable the test LED.
N.B. To put ALL zones into test enter 00 for the zone number.
The Local Audible Test function allows the selection of one or more
detection-zones to operate in a ‘one-man walk test mode with local
sound’. On triggering a device, the device LED operates, the sounders
within that zone operate and the control panel indicates an alarm. After
approximately 5 seconds, the system will reset the device and another
may be tested. The control panel event log will indicate that a test
mode has been selected.
N.B. To put ALL zones into test enter 00 for the zone number.
The System Test function allows the selection of one or more
detection-zones to operate in a ‘one-man walk test mode with local
sound’. On triggering a device, the device LED operates, the
sounders within that zone operate and the control panel indicates an
alarm. After approximately 5 seconds, the system will reset the
device and another may be tested. The control panel event log will
indicate that a test mode has been selected.
N.B. To put ALL zones into test enter 00 for the zone number.
2. Test Modes
1. Test Cntrl & Display
4. Test Keyboard
2. Test Modes
2. Test Zone
1. Silent Test
2. Test Modes
2. Test Zone
2. Audible Test
2. Test Modes
2. Test Zone
3. System Test
01/09/09 22:26 ENGR
KEYBOARD TESTING..
ENTER key PRESSED.
Press Enter Key
01/09/09 22:26 ENGR
SILENT TEST (ZONES).
ENTER ZONE:00
Press Enter Key
01/09/09 22:26 ENGR
TEST ZONE 01
1.START 2.END
Press <> OR Esc Key
01/09/09 22:26 ENGR
AUDIBLE TEST (ZONES)
ENTER ZONE:00
Press Enter Key
01/09/09 22:26 ENGR
TEST ALL ZONES
1.START 2.END
Press <> OR Esc Key
01/09/09 22:26 ENGR
SYSTEM TEST (ZONES)
ENTER ZONE:00
Press Enter Key
01/09/09 22:26 ENGR
TEST ALL ZONES
1.START 2.END
Press <> OR Esc Key
