ESP MAGDUO8B - Access Level 2 A (User)

MAGDUO Control Panel Engineering and Commissioning Manual
26-1649-03
Access Level 2A (User): Enable Controls LED on
At Access Level 2A (User), the main Fire Alarm Controls are enabled and the following System
Controls are accessible:
These are described below. Note that actual display indications may differ from those shown in the grey
boxes below, depending on actual set up.
The Active Log will display any current fires. These are displayed in
text format and may be scrolled through by pressing the UP and
DOWN keys. Press the ESC key to exit the menu.
The Active Log will display any current faults. These are displayed in
text format and may be scrolled through by pressing the UP and
DOWN keys. Press the ESC key to exit the menu.
The Active Log will display any current disables. These are displayed
in text format and may be scrolled through by pressing the UP and
DOWN keys. Press the ESC key to exit the menu.
USER (1111)
1. View Current Events
1. Current Fires
2. Current Faults
3. Current Disables
4. Current Warnings
1. Test Cntrls & Display
2. Test Modes
1. Test LCD Display
2. Test LEDs
3. Test Buzzer
4. Test Keyboard
1. View Current Events
1. Current Fires
1. View Current Events
2. Current Faults
1. View Current Events
3. Current Disables
FIRE 001 OF 001
Z01: ZONE 01
Press <> OR Esc Key
FAULT 001 OF 001
Z00: NA
Batt – Low Vtg
Press <> OR Esc Key
01/09/09 22:26 USER
01.REMOTE FIRE
Press <> OR Esc Key
