MAGDUO Control Panel Engineering and Commissioning Manual
26-1649-03
Commissioning Checklist
The following checklist may be used to ensure that all steps are taken. This is not a BS5839 certificate
and serves as a reminder only and may need additional items added to suit your working practices.
Step 1
Commissioning
Engineer Checked
Panel powered up (230V AC Mains first, then batteries). Nothing else
connected. All zones showing fault.
Program the number of ‘Active’ zones required, check that zones not required
are clear of fault.
Low voltage multimeter test of cables to show no inter-core short circuits.
End of Line device installed with EOL switch in the ON position and remainder
of devices added with DIL switches set, then each zone connected with
approx 30 - 50 secs allowed to clear fault condition.
All faults (device, input, output, EOL, battery, etc,) cleared from control panel.
Step 2
Control panel programmed for any additional features.
All other cables connected and clear of fault.
Step 3
Correct operation of all input devices tested, ie. detectors, manual call points
and inputs.
Correct operation of all output devices tested, ie. sounders, relays and
outputs.
Correct operation of all programmed actions tested, ie. instant alarms,
confirmation alarms, two stage alarms.
Step 4
System Manuals completed, zone chart or zone list displayed.
End user or responsible person trained and user manual issued.
