Technical Data
Control Panel Specification
2 Zone Panel
4 Zone Panel
8 Zone Panel
Dimensions (mm)
331 x 331 x 99
Weight (excluding
batteries)
2.25 kg
2.28 kg
2.36 kg
Construction
V0 rated ABS
IP Rating
IP 30
Cable Entry
13 x 20mm knockouts 1 x 50mm x 50mm pull out tab
Cable type
2 core 1.5mm
2
screened fire rated cable, 500m (max per zone)
Detection zones
2 Max
4 Max
8 Max
Devices per zone
Up to 32 Devices dependant on Device Loading Units (DLUs) not exceeding
the stated maximum loading.
Device Protocol
MAGDUO
Monitored sounder circuits
Up to 2
Monitored relay circuits
Up to 2
Relays on board
Common fire and common fault
Operating standard
BS EN54-2 & 4
Operating temperature
5
O
C to 40
O
C
Control Panel Ratings
2/4/8 Zone Panel
Mains voltage
230V AC Nominal 700mA
PSU output (4 hour continuous)
2.1A
Operating voltage
Nominal 24V DC (Range 21-31V DC)
Battery charger output
300mA Max
Charger high impedance voltage
<4V DC
Battery voltage (During Charge)
27.3 V DC @ 20
O
C
Internal Battery capacity
2 x 12V 3.2Ah (or 3.3 Ah) or 2 x 12V 3.2 Ah, Max load 1.8A
Maximum Internal resistance
including connections and Fuse
1.3R
Zone output (max)
160 mA
MAGDUO zone voltage (nominal)
30V DC
Conventional zone voltage (nominal)
20V DC
Monitored Outputs 1 and 2
(max, fused)
300 mA trip polyfuse
Monitored Outputs 1 and 2 EOL
10k
Monitored Outputs 1 and 2 DC
supply Current (max)
250 mA for a 2 – 4 zone panel
200mA for an 8 zone panel
Auxiliary DC supply Current (max)
250 mA
Auxiliary DC supply Volts,
Unregulated
21V – 31V DC
Common fire relay
Volt free SPCO contacts 1A 30V max
Common fault relay
Volt free SPCO contacts 1A 30V max
Loading
160 DLUs max per zone
2 zone Imin (Required by EN54-4)
30mA @24V
4 zone Imin (Required by EN54-4)
40mA @ 24V
8 zone Imin (Required by EN54-4)
60mA @24V
Imax.a (Required by EN54-4)
350mA
