selected zone will be delayed for the
time period set in the ‘Delay Timer’
menu.
This active control will allow the engineer to set an alarm delay for the
panel fire relay. Use the LEFT and RIGHT keys to toggle through the
following options. Once the correct option has been selected, press the
ENTER key.
1. INSTANT – When the panel receives a fire input
the fire relay will immediately activate.
2. DELAYED – When the panel receives a fire input
the fire relay will be delayed for the
time period set in the ‘Delay Timer’
menu.
This active control will allow the engineer to set an alarm delay for
Monitored Output 1. Use the LEFT and RIGHT keys to toggle through
the following options. Once the correct option has been selected, press
the ENTER key.
1. INSTANT – When the panel receives a fire input
Monitored Output 1 will immediately
activate.
2. DELAYED – When the panel receives a fire input
Monitored Output 1 will be delayed for
the time period set in the ‘Delay Timer’
menu.
This active control will allow the engineer to set an alarm delay for
Monitored Output 2. Use the LEFT and RIGHT keys to toggle through
the following options. Once the correct option has been selected, press
the ENTER key.
1. INSTANT – When the panel receives a fire input
Monitored Output 2 will immediately
activate.
2. DELAYED – When the panel receives a fire input
Monitored Output 2 will be delayed for
8. Alarm Delay
2. Delay Fire Relay
8. Alarm Delay
3. DLY monitored O/P1
1
8. Alarm Delay
4. DLY monitored O/P 2
01/09/09 22:26 ENGR
FIRE RELAY: INSTANT
1.INSTANT 2.DELAYED
Press <> OR Esc Key
01/09/09 22:26 ENGR
MON O/P 1 : INSTANT
1.INSTANT 2.DELAYED
Press <> OR Esc Key
01/09/09 22:26 ENGR
MON O/P 2 : DELAYED
1.INSTANT 2.DELAYED
Press <> OR Esc Key
