Estella 236ECEM2 Service Manual

21
Group Head Filter and Gasket
Time Estimate: Approximately 15 min.
1. Follow pre-maintenance steps from page 10
2. Remove 2 screws from top front cover and
remove cover (Fig. 57)
3. Remove top brass hex head plug (Fig. 58)
with 16mm socket
4. Replace washer as required (Fig. 59 A)
#236PECEM25
5. Replace fi lter as required (Fig. 59 B)
#236PECEM26
6. Remove group head nozzle with 8mm
socket, replace as required (Fig. 60)
#236PECEM19
7. Reassemble by reversing steps
Fig. 57
Fig. 59
Fig. 60
Fig. 58
A
B
