Estella 236ECEM2 Service Manual

22
1. Follow pre-maintenance steps from page 10
2. Remove 2 screws from top front cover and
remove cover (Fig. 61)
3. Pry off cap from steam wand knob (Fig. 62)
AND/OR
Pry off cap from hot water nozzle knob
4. Remove co er pin from inside each knob
(Fig. 63)
5. Slide each knob off adjus ng tap valve
6. Remove hot water nozzle (Fig. 64) and/or
steam wand (Fig. 65)
7. Remove hex nut from copper inlet pipe
(Fig. 66 A)
8. Remove brass hex nut from valve moun ng
bracket (Fig. 66 B) with 24mm wrench
9. Replace gasket plug as required (Fig. 67)
#236PECEM29
10. Reassemble by reversing steps
Fig. 61
Fig. 66
Fig. 67
Fig. 63
Fig. 65
Fig. 62
Fig. 64
A
B
Steam and Hot Water Plug
Time Estimate: Approximately 20 min.
