10. Technical data
10.1. Technical data ECoSDetector
Technical data ECoSDetector
Operating modes
Direct bus connection to ECoSlink. Operation with ECoS
or Central Station «Reloaded» possible.
Feedback
16 feedback inputs. Configurable via jumpers as digital
inputs (e.g.: for track switches or reed contacts) or as oc-
cupancy detector (current sensor).
Galvanic separation of the feedback inputs from the com-
mand station.
Maximum current 3A per feedback input.
RailCom®
4 of the 16 feedback inputs are configurable as RailCom
feedback inputs («local detector»). Detection of the lo-
comotive address.
Dimensions 86mm x 86mm x 25mm
Scope of delivery
feedback module, terminals, ECoSlink bus cable, detailed
manual
10.2. Technical data ECoSDetector Standard
Technical data ECoSDetector Standard
Operating modes
Direct bus connection to ECoSlink. Operation with ECoS
or Central Station «Reloaded» possible.
Feedback
16 feedback inputs as digital inputs (e.g.: for track swit-
ches or reed contacts).
Galvanic separation of the feedback inputs from the com-
mand station
Dimensions 86mm x 86mm x 25mm
Scope of delivery
ECoSDetector Standard feedback module, terminals,
ECoSlink bus cable, detailed manual
Technical data
11. Support and Assistance
Your model train dealer or hobby shop is your competent partner
for all questions regarding your LokPilot decoder. In fact he is your
competent partner for all questions around model trains.
There are many ways to get in touch with us. For enquiries please
use either email, fax (please provide your fax-no. or email address)
or go to www.esu.eu/en/forum and we will reply within a few
days.
Please call our hotline only in case of complex enquiries that can’t
be dealt with by email or fax. The hotline is often very busy and
you may encounter delays. Rather send an email or fax and also
check our website for more information. You will find many hints
under “Support / FAQ” and even feedback from other users that
may help you with your particular question.
Of course we will always assist you; please contact us at:
USA & Canada (English support), please contact:
Phone: +1 (570) 649-5048
Tuesday & Thursday 9:00am - 3:00pm (CT)
Fax: +1 (866) 591-6440
Email: support@loksound.com
Mail: ESU LLC
477 Knopp Drive
US-PA-17756 Muncy
Germany and all other countries, please contact:
Fax: ++49 (0) 731 - 1 84 78 - 299
Email: www.esu.eu/en/forum
Mail: ESU GmbH & Co. KG
- Technical support -
Edisonallee 29
D-89231 Neu-Ulm
www.esu.eu
