1. EG - Declaration of conformity
We, ESU electronic solutions ulm GmbH & Co. KG, Edisonallee
29, D-89231 Neu-Ulm, Germany, declare in sole responsibility that
the product
Product description: ECoSDetector
Part number: 50094, 50096
complies with all relevant regulations of the Directive for Electro-
magnetic Compatibility (2004/108/EG). The following harmonised
standards have been applied:
EN 55014-1:2006 + A1:2009: Electromagnetic Compatibility -
requirements for household appliances, electric tools, and similar
apparatus - Part 1: Emission - Product
EN 55014-2:1997 + A1:2001 + A2:2008: Electromagnetic Compa-
tibility - Requirements for household appliances, electric tools, and
similar apparatus - Part 2: Immunity - Product family standard.
2. WEEE-Declaration
Disposal of obsolete electrical and electronic equipment (as prac-
tised in the European Union and other European countries with
dedicated collection systems).
This mark on the product, the packaging or the
relevant documentation indicates that this product
must not be treated like household waste. Instead
this product should be disposed of at a suitable
collection point for recycling of electrical and elec-
tronic appliances. Thus you contribute to avoid
negative impact on the environment and people’s health that
could be caused by inappropriate disposal. Recycling of materials
contributes to preserve our natural resources. For more informa-
tion regarding recycling of this product, please contact your local
authority, your waste collection service or the dealer / shop where
you purchased this product.
3. Important Notes – Please read first
We congratulate you to your purchase of an ESU ECoSDetector
feedback module. This manual provides step by step information
on the various options of use of this device. Therefore we have
one request:
Please read this manual carefully prior to commissioning. Alt-
hough the circuit board is quite robust incorrect wiring could lead
to damage or destruction of the module. If in doubt, please refrain
from any “expensive” experiments.
• The ECoSDetector is solely intended for use on electric model
train layouts. It may only be operated with the components de-
scribed in this manual. Any other use as described in this manual
is not permitted.
• All electrical work such as wiring the module may only be car-
ried out when power is turned off.
• Avoid any impact load or pressure against the module.
• Keep away from wet conditions or humidity.
• The circuit board may not get into contact with any metal ob-
jects or electrical conductors. This is particularly true for the
track signal.
• Never let your trains run unattended.
3.1. Scope of delivery
Please check if the following parts are in the packaging of your
ECoSDetector:
1x ECoSDetector respectively ECoSDetector Standard
1x Accessory bag (with 4 nos. 4-way terminal blocks, 2 nos. 2-way
terminal blocks)
1x ECoSlink connecting cable
1x Manual (which you are reading right now)
Important notes
