Esu SwitchPilot 3 51830 - 17 List of All Supported Cvs

32
17. Liste aller unterstützten CVs
CV Name Description Range Value
1 Decoder address 1,
LSB
Lower 6 bits (bit 0 - 5) of the first decoder address for outputs 1 to 4. Used together with CV
9 to save the address.
1 - 63 1
3 Configuration
Output 1
Defines the properties of decoder output 1. 0 - 64 8
Function Description Value
Moment
business
K83-compatible: output active as long as the button on the control
panel is pressed.
0
Impulse ope-
ration PECO
Impulse operation for PECO drives. Reduces the sensitivity of the
overcurrent protections.
1
Impulse ope-
ration
Duty cycle: multiple of 65 ms. 2 - 31
Alternating
indicators
Out A and Out B alternately active. Duty cycle: multiple of 130 ms 32 - 63
Continuous bis-
table operation
K84 compatible: Either Out A or Out B active, permanent output 64
4 Configuration
Output 2
Defines the properties of decoder output 2. 0 - 64 8
Function Description Value
- As CV 3 -
5 Configuration
Output 3
Defines the properties of decoder output 3. 0 - 64 8
Function Description Value
- As CV 3 -
6 Configuration
Output 4
Defines the properties of decoder output 4. 0 - 64 8
Function Description Value
- As CV 3 -
7 Version number Internal software version of the decoder. 193
8 Manufacturer ID Manufacturer number (ID) of ESU. Writing the value 8 resets all CV to the factory
setting.
- 151
9 Decoder address 1,
MSB
Upper 3 bits (bits 6 - 8) of the first decoder address for outputs 1 to 4.
Used together with CV 1 to save the address.
0 - 7 0
CV Name Description Range Value
28 RailCom
Configuration
Activation and configuration of the RailCom function 0,2 2
Bit Description Value
1 Data transmission on channel 2
No data transmission on channel 2
Data transmission allowed on channel 2
0
2
29 Configuration
register
DCC configuration settings for the SwitchPilot 128,136 128
Bit Description Value 136
3 RailCom communication
RailCom communication is switched off 0
RailCom communication allowed 8
7 Decoder is DCC Accessory Decoder (solenoid) 128
(read only, cannot be changed)
34 „Zoom“-
Configuration
Determination of which of the outputs 1 - 4 should „zoom” when switched on
/ off. „Zoom” means slowly fading in or out of the function. This can be used to
create a prototypical cross-fading of light signals.
0 - 15 0
Bit Description Value
0 „Zoom” function active for output 1 1
1 „Zoom” function active for output 2 2
2 „Zoom” function active for output 3 4
3 „Zoom” function active for output 4 8
35 Decoder address 2,
LSB
Lower 6 bits (bits 0 - 5) of the second decoder address for outputs 5 to 8. Used together with
CV 36 to save the address.
1 - 63 2
36 Decoder address 2,
MSB
Upper 3 bits (bits 6 - 8) of the second decoder address for outputs 5 to 8.
Used together with CV 36 to save the address.
0 - 7 0
37 DCC turnout
addressing
Calculation of the turnout numbers from the decoder address 0,1 0
Bit Description Value
0 DCC turnout addressing compliant with RCN-213
DCC turnout addressing for ROCO centers
0
1
42 Fadein / Fadeout
Time
Duration of the fade-in & fade-out process in 65ms steps, if configured for the output. 0 - 63 2
