Example with heating pipeline Examples
Connections
= type [Heating water]
= type [SolarMedium]
Producers Consumers
HA-C 0: Boiler: Flow GM-C 0: Buffer: .
GM-C 0: Buffer: HC/HWT GM-C 0: HC: .
GM-C 0: Pipel: .
GM-C 0: Buffer: FWM GM-C 0: FWM: .
GM-C 0: Pipel: Flow GM-C 1: Buffer1.1: .
GM-C 1: Buffer1.1: HC/HWT GM-C 1: HC1.1: .
GM-C 1: HW1.1: .
GM-C 1: Solar1.1: Tank 1 bottom GM-C 1: Buffer1.1: Solar bottom
GM-C 1: Solar1.1: Tank 2 bottom / Tank 1 top GM-C 1: HW1.1: Solar bottom
