Examples Example with heating pipeline
Select the required function block from the [Possible
function blocks] column:
Add the function block. The following option is required
for changeover between the buffer and the hot water
tank.
Press the [Accept] button to save.
Continue configuration
Continue the configuration by pressing the [Next]
button.
5.2.3 Creating connections
Creating the [Heating water] connection
Create a new connection by pressing [New connec-
tion].
Select the [Heating water] connection type from the
displayed list.
The new connection appears in the [Connections]
window.
Now specify the producers and consumers for this
connection. These are listed in the following table:
Creating the [Heating water] connection
A producer can be connected with several
consumers as in this example with the heating
circuit and the heating pipeline.
Create a new connection by pressing [New connec-
tion].
Select the [Heating water] connection type from the
displayed list.
The new connection appears in the [Connections]
window.
Specify the producers and consumers. These are
listed in the following table:
Creating the [Heating water] connection
The fresh water module has its own producer and
consumer. You therefore need to create a
separate connection.
Create a new connection by pressing [New connec-
tion].
Select the [Heating water] connection type from the
displayed list.
The new connection appears in the [Connections]
window.
Possible function blocks
GM-C 1
Solar panel
2 tanks + diverter valve
Connections
Heating water
Producers
HA-C 0: Boiler: Flow
Consumers
GM-C 0: Buffer: .
Connections
Heating water
Producers
GM-C 0: Buffer: HC/HWT
Consumers
GM-C 0: HC: .
GM-C 0: Pipel: .
