ES441.1 - User’s Guide72
Getting Started ETAS
Rules on Attaching the Modules to Other Components
Observe the following rules when connecting the modules as required to other
components:
Preparing the Component
To cut the thread in the component:
1. Cut two M3 threads into the selected component.
The threads should be cut 8 mm deep.
Connecting the Module to the Component
To connect the ES400 module to the component, you require a 2 mm Allen key
(minimum length 20 mm).
To connect the module and the component:
1. Position the module to the right of the other com-
ponent.
2. Align the integrated assembly elements of the mod-
ule with the drill holes.
3. Insert the Allen key into a hexagon socket on the
right-hand side of the module.
4. Screw the two parts together by turning the Allen
key clockwise as far as it will go within the module.
Both parts are now connected mechanically on one
side.
5. Insert the Allen key into the other hexagon socket
of the module.
The two integrated assembly elements can only be accessed from the right-
hand side of the module and can only be turned using an Allen key.
You therefore have to screw the module to the other component from the
right.
You can only successively screw additional modules, but not module blocks,
onto the right-hand side of this module.
Use the drilling template (see Fig. 6-13 on page 82).
Screw the two parts together without getting them
off-thread!
