Home Screen Displays
Depending on the fixture settings, the following are displayed in the system message area
on the respective home (status) screens.
The following chart pertains to all fixtures except Daylight and Tungsten.
The following chart pertains to Daylight and Tungsten fixtures only.
Profile (excluding Daylight and Tungsten)
The control profile defines the number and control parameter assignments of input
channels for intensity and color-control. For more information, see Profiles, page 23.
Profile (Daylight and Tungsten only)
The control profile for Daylight and Tungsten includes only the Direct or Studio options. The
first channel of DMX control adjusts fixture Intensity from 0 to 100%. For more information,
see Daylight and Tungsten, page 27.
Output Setting
Output is the way and amount to which the fixture constrains the overall power going to the
LED array, which determines how consistent the fixture’s brightness may be. For more
information, see Output, page 48.
Dimming Curve
Dimming curve is the way that the fixture responds to changes in the control signal for
overall intensity. For more information, see Curve, page 49
Red Shift
Red shift replicates the warming of an incandescent filament’s color temperature change
as it dims. For more information, see Red Shift, page 51.
Strobe
Strobe flashes the output of the LED array. For more information, see Strobe, page 45.
Parameter Stage XT Arch High Impact Studio General
Profile HSI HSI RGB Studio
Direct Control
(Dir)
Output Setting
Regulated
(Reg)
Protected
(Prt)
Boost
(Bst)
Regulated
(Reg)
Regulated
(Reg)
Dimming Curve
Incandescent
(Incd)
Standard
(Stnd)
Quick
(Qik)
Linear
(Lin)
Standard
(Std)
Red Shift (RS) Enabled Disabled Disabled Disabled Disabled
Strobe (Str) On On On On On
Parameter Studio Stage Single Channel
Profile Studio Direct Direct
Output Setting Regulated (Reg) Regulated (Reg) Regulated (Reg)
Dimming Curve Linear (Lin) Incandescent (Incd) Standard (Std)
Strobe (Str) On On Off
Fan Control DMX DMX Automatic (Auto)
