Appendix A
Quick Start
This section will help users to quickly use the Source Four LED fixture. For complete,
detailed information and step-by-step instructions, see Operation, page 39.
Install
Step 1: Hang or mount the fixture using the provided hardware and approved hardware
accessories.
Step 2: Attach an approved safety cable when applicable.
Step 3: Insert additional accessories (top hat, etc.) into the holder, if desired.
Connect
Step 1: Attach the power cable to the Power In connector.
Step 2: Attach 5-pin XLR cable to the DMX In connector (if using external control).
Step 3: Plug the power cable into AC power (100 to 240VAC, 50/60 Hz) on a
non-dimmable circuit.
Step 4: Plug the XLR cable (if using) into the DMX source or data daisy-chain.
Step 5: Link additional fixtures via the Power Out and DMX Out connectors using the
following guidelines.
• No more than nine total Source Four LED (four total Series 2 Lustr) fixtures
on Power Thru.
• Up to 32 device loads on the DMX daisy-chain.
Focus
Step 1: With power supplied, wait for the fixture to boot up. This will take approximately
ten seconds.
Step 2: Press [] to open the Presets & Sequences menu.
Step 3: Select Focus and then press []. This turns the LED array on to enable
focusing.
Step 4: Adjust the fixture's position as needed.
Step 5: When focusing is complete, press [] to restore the fixture to its original preset.
Step 6: Select [] to return to the home screen.
For information about the user interface, see User Interface Overview, page 34.
CAUTION:
The fixture must be connected to a non-dimmable power source in order to avoid
damage to its internal power supply and other electrical components. Dimming will
damage the fixture and void the warranty.
