Generator G11 Operator’s Manual
Appendix
System Specifications
Main Fuses T5AL 250 V (Time-delay, 5 Amp, glass body, 5x20 mm package size, quantity: 2)
Degree of Protection Against Electric Shock Type CF applied part consisting of the HARMONIC or ENSEAL instruments
Class of Protection Against Electric Shock Class 1
Ingress Protection G11 Enclosure
Ingress Protection G11 Footswitch
IP21
IP68
Main Input
100 - 240 V
~
, 50/60 Hz, 500 VA
Output ENSEAL Output:
Bipolar, no neutral electrode required
100 VAC RMS maximum
135 watts maximum (rated load 15 ohms, unless otherwise specified in the instrument IFU)
300 - 490 kHz (330 kHz, unless otherwise specified in instrument IFU)
HARMONIC Output:
150 VAC RMS maximum (Unless otherwise specified in the instrument IFU)
35 watts continuous (Unless otherwise specified in the instrument IFU)
30 - 80 kHz (55�5 kHz unless otherwise marked in instrument IFU)
Ambient Operating Conditions Temperature: 15 °C to 27 °C
Humidity: 30% - 75% non-condensing
Atmospheric Pressure Range: 700 hPa - 1060 hPa
Transport and Storage Conditions Temperature: -35 °C to +54 °C
Humidity: 10% - 95% non-condensing
Atmospheric Pressure Range: 700 hPa - 1060 hPa
Weight Generator: 5�9 kg
Cart: 16�8 kg
Footswitch: 3�6 kg
Overall Dimensions Generator: 35�0 cm x 35�5 cm x 13�6 cm
Cart: 48�0 cm x 56�2 cm x 95�3 cm
Footswitch: 34�2 cm x 19�0 cm x 10�4 cm
Power Cord North American removable power cord set with the following characteristics:
Plug Style: NEMA 5-15 (clear) North American Hospital Grade
Receptacle: IEC 60320 C13 with straight non-angled cord entry
Cord Length: 4�6 meters nominal
Current Rating: 13A
Voltage Rating: 125 VAC minimum
Wiring Code: North American
Cordage Description: SJT (UL) or SJT (CSA)
Conductors: 16 AWG 3C
Agency Approvals Required: UL and CSA
International removable power cord set with the following characteristics:
Plug Style: as needed by particular country requirements
Receptacle: IEC 60320 C13 with straight non-angled cord entry
Cord Length: 2�44 - 4�6 meters nominal
Current Rating: 10A
Minimum conductor size cross-sectional area: 1�0 mm
2
copper
Voltage Rating: 250 VAC minimum
Wiring: International
Cordage Type: HAR
Item to have certification by at least one of the following agencies: VDE, ASTA, SEMKO,
KEMA, LCIE, DFT, IMQ, SEV
